Manufacturer
Automatic Hydraulic Chamber Filter Press Sludge Dewatering Solid-Liquid Separation Plate and Frame Filter Press
USD 4500.00 – 18900.00
/ piece
Price varies by quantity and specifications
| MOQ | 1 piece |
| Category | Machinery |
26
Years
98%
Response
24h
Reply
More from this Supplier
Product Description
No detailed description available. Please send an inquiry for more information.
Technical Specifications
| Model NO. | MXZ/1000-UA |
| Structure | Belt Type |
| Filter Material | PE |
| Pressure | Hydraulic Pressure |
| Type | Chamber Filter Press |
| Product Name | Sludge Dewatering Plate and Frame Filter Press |
| Model | Mxz/1000-Ua |
| Filter Area (M2) | 100 |
| Filter Board Specification (mm) | 1000*1000 |
| Thickness of Press Plate (mm) | 30 |
| Number of Filter Plate (Piece) | 58 |
| Cubage of Filter Chamber (L) | 1480 |
| Maximum Cylinder Stroke (mm) | 550 |
| Filtering Pressure(MPa) | 0.5 |
| Machine Weight(Kg) | 4360 |
| Transport Package | Carton |
| Specification | 5890*1500*1350mm |
| Trademark | Gloyel |
| Origin | China |
| HS Code | 8421291090 |
