Customized Metal Rod, Pipe Straightening Machine, Multi-Rollers Straightening Machine, Metal Straightener
USD 30000.00 – 100000.00
/ set
Price varies by quantity and specifications
| MOQ | 1 set |
| Category | Machinery |
14
Years
98%
Response
24h
Reply
More from this Supplier
Product Description
No detailed description available. Please send an inquiry for more information.
Technical Specifications
| Model NO. | Customized |
| After-sales Service | Enterprise Life Time Service |
| Type | Balance Roller Straightening Machine |
| Usage | Wire, Pipe, Bar |
| Voltage | 380V |
| Automatic Grade | Automatic |
| Principle | Large Deformation |
| Certification | TUV, CCC, ISO9001 |
| Warranty | 12 Months |
| Customized | Customized |
| Condition | New |
| Type | Balance Roller Straightening Machine |
| Usage | Wire, Pipe, H Beam Flange, Bar, Wire, Pipe, Bar, Rod/Hex/Square Rod and Pipe |
| Voltage | 380V |
| Automatic Grade | Automatic |
| Certification | TUV, ISO9001, ISO9001, CE |
| Warranty | 12 Months |
| Customized | Customized |
| Condition | New |
| After-Sales Service | Long Term After Sales Service |
| Principle | Small Deformation, Customized |
| Model No. | Ygj40 |
| Diameter Range | Ф10-40mm |
| Yield Limit | ≦420 N/mm² |
| Straightening Speed | 30 M/Min |
| Angle Adjustment Range | 27-33 Degree |
| Straightening Roller Throat Diameter | Φ130mm |
| Roller Length | 175mm |
| Allowable Bending Before Straightening | ≦30 mm/M |
| Once Straightening Bend mm/M | ≦1 mm/M |
| Motor Type | Byw-23 |
| Motor Power | 7.5 Kw×2 |
| Motor Turning Speed | 1480 R/Min |
| Machine Weight | 5100 Kg |
| Rollers Layout | 2-2-2-1 |
| Transport Package | Wooden Plate |
| Specification | Customization |
| Trademark | DT INDUSTRY |
| Origin | China |
