Haitian MAII 650T High Precision Injection Molding Machine with Servo Motor System
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4 Thumbnail 5 Thumbnail 6
Trading Company

Haitian MAII 650T High Precision Injection Molding Machine with Servo Motor System

USD 42700.00 – 43900.00 / piece
Price varies by quantity and specifications
MOQ 1 piece
Category Machinery
Submit Order
Dirma Machinery (Dongguan) Co., Ltd

China

Trading Company
26
Years
98%
Response
24h
Reply
Chat Now
More from this Supplier
Industrial Used Bucket Mold with Thick Anti-Wear Steel Plates
Industrial Used Bucket Mold with Thick Anti-Wear Steel Plates
USD 2600.00
Multi-Layer 300kg Seal Vertical Mixer with Zero Dust Overflow Design Shell
Multi-Layer 300kg Seal Vertical Mixer with Zero Dust Overflow Design Shell
USD 1500.00
100kg Vertical Mixer with Frequency Conversion Control Motor
100kg Vertical Mixer with Frequency Conversion Control Motor
USD 520.00
900g Suction Machine with Explosion-Proof Motor Drive
900g Suction Machine with Explosion-Proof Motor Drive
USD 400.00
Soundproof Low-Noise 850g Suction Machine with Vibration Damping Rubber Feet
Soundproof Low-Noise 850g Suction Machine with Vibration Damping Rubber Feet
USD 380.00
Precision Temperature-Control 10HP Water-Cooled Chiller with Digital Display
Precision Temperature-Control 10HP Water-Cooled Chiller with Digital Display
USD 1230.00

Product Description

No detailed description available. Please send an inquiry for more information.

Haitian MAII 650T High Precision Injection Molding Machine with Servo Motor System
Haitian MAII 650T High Precision Injection Molding Machine with Servo Motor System

Technical Specifications

Model NO.HaiTian MAlll 650T
After-sales ServiceServices Are Available Upon Request
Warranty1 Year
TypeInjection Blow Molding
StructureHorizontal
Plastic TypeThermoplastic
Plasticizing WayScrew Type
Clamping WayHydraulic
AutomationAutomatic
ComputerizedComputerized
CertificationCE, ISO9001:2008, GMP, QS
Screw Diameter B90mm
Screw L/D Ratio22
Shot Size2576cm3
Injection Weight2344G
Injecction Rate620g/S
Plasticizing Capacity71.8g/S
Clamp Tonnage6500kN
Toggle Stroke900mm
Space Between Tie Bars895mm
Max.Mold Height900mm
Ejector Stroke260mm
Pump Motor Power22+45kw
Heater Power49.25kw
Machine Weight30200kg
Transport PackagePlastic Wrap Film Packaging
Specification10.1m*2.32m*2.7m
TrademarkHaitian
OriginThe Chinese Mainland
HS Code84771000
