Lower Limb Rehabilitation Training System with 3 Denmark LINAK Linear Motors for Stable Gait Therapy
| MOQ | 1 Pack |
| Category | Medical |
More from this Supplier
Product Description
Product Description
Design principle: Neuroplasticity principle
Adaptation diseases:
Early term rehabilitation training
Imperfect walk and motion, lack of motion, multiple sclerosis, rheumatism, cardiomyopathy, arthritis,
deformity, parkinsonism, paralysis, lump, edema, dialysis, amyotrophy and so on.
Function
Ø Stimulate proprioception.
Ø Three-in-one: Standing bed, support body weight and gait training.
Ø Highly imitate normal physiological gait.
Ø Passive and active training, gait analysis, gait evaluation.
Ø Spasm detection and protection
Ø Strong software function: Build up patient database, show force curve in real time, game training, voice prompt, dysfunction alarm.
Ø Hypsokinesis angle range: 0~10°: Lift some part of patient’s upper body weight which makes patient feel
safer and help patient relax the whole body muscle for training.
Characteristic
Ø Strong compatibility: Set and train each leg independently, universal footboard makes it suitable for
the valgus and varus, uneven leg length.
Ø Game training in scene: increase training interest and reduce training baldness.
Specification
| MODEL | A1 | |||
| Edition Optional | a) Child edition | b) Training edition | c) Standard edition | d) Enhence size |
| Package Size | a) | 2400mm×990mm×690mm | ||
| CBM | a) | b) 1.64m³ | ||
| Net weight | 213kg | 220kg | ||
| Gross weight | 280kg | |||
| Loading Quantity(20GP) | ||||
| Loading Quantity(40HQ) | ||||
| Delivery Time | 15 days | 15 days | ||
| Colour | a) As the pic showed | b) Customerization | ||
| Package | a) Bubble bag(transparent EPE bag)+transparent & dustproof polybag+wood carton | |||
| b)Customerization | ||||
| Additional: corner protection & kraft | ||||
| MOQ | 1 pcs | |||
| Payment Terms | a) T/T | b) L/C | ||
| Warranty | a) One year against manufacturing defect | |||
| b) Offer lifetime consultation on problems occurred | ||||
| Specification | a) Child edition | b) Training edition | c) Standard edition | d) Enhence size |
| Adjustable bed height range | 52~86cm | |||
| Standing angle range | 0~80° | 0~80° | ||
| Hypsokinesis angle range | 0~10° | 0~10° | ||
| Spasm sensitivity | 3 level difficulty for adjusting. | |||
| Hip motion range(unit: 1/2°) | 0~25° | 0~25° | ||
| Step speed | 1~80steps/min | 1~80steps/min | ||
| Treatment time | 1~60 minutes | 1~60 minutes | ||
| Max load | 60Kg | |||
| Patient height | 95~145cm | |||
| Product size | 150(L)×68(W)×62(H)cm | 260(L)×100(W)×270(H)cm | ||
Specification
Ø Adjustable bed length range: 52~86cm
Ø Standing angle range: 0~80°
Ø Hypsokinesis angle range: 0~10°
Ø Spasm sensitivity: 3 level difficulty for adjusting.
Ø Motion range: 0~25°, unit: 1/2°
Ø Step speed: 1~80steps/min
Ø Treatment time: 1~60 minutes
Technical Specifications
| Place of Origin | Guangdong, China |
| Warranty | 3 Years |
| After-sale Service | Online Technical Support |
| Instrument classification | Class II |
| Operation System | Windows XP system installed in portable dual core laptop |
| Table driven devices | 3 Denmark LINAK linear motors |
| Maximum rated output air pressure | 150mmHg±15mmHg |
| Bed Adjustable length range | 52~86cm |
| Bed Tilting Angle | 0~80° |
| Backrest Reclining Angle | 0~10° |
| Features | durable, wear resistant, highly elastic and comfortable |
| Motion range | 0~25°, unit: 1/2° |
| Step speed | 1~80steps/min |
| Treatment time | 1~60 minutes |
| Design principle | Neuroplasticity principle |
| Function | Stimulate proprioception; Three-in-one: Standing bed, support body weight and gait training; Highly imitate normal physiological gait; Passive and active training, gait analysis, gait evaluation; Spasm detection and protection; Strong software function: Build up patient database, show force curve in real time, game training, voice prompt, dysfunction alarm; Hypsokinesis angle range: 0~10° |
| Characteristic | Strong compatibility: Set and train each leg independently, universal footboard makes it suitable for the valgus and varus, uneven leg length; Game training in scene: increase training interest and reduce training boredom |
| MOQ | 1 pcs |
| Package | Bubble bag(transparent EPE bag)+transparent & dustproof polybag+wood carton, optional corner protection & kraft |
| Net weight | 213kg/220kg |
| Gross weight | 280kg |
| Package Size | 2400mm×990mm×690mm |
| CBM | 1.64m³ |
| Delivery Time | 15 days |
